Section 07 TRANSMISSION
Subsection 03 (DRIVEN PULLEY)
DRIVEN PULLEY
SERVICE TOOLS
Description Part Number Page
driven pulley spring compressor...........................................
529 035 300
.................................371, 373
extractor ............................................................................... 529 035 575 .........................................375
pulley spring compressor ....................................................
529 035 524 .........................................375
pulley spring compressor .....................................................
529 035 524
......................... 375–376, 379
spring scale hook..................................................................
529 006 500 .........................................379
support plate.........................................................................
529 031 100 .........................................375
SERVICE PRODUCTS
Description Part Number Page
anti-seize lubricant................................................................ 413 701 000
......................... 373, 376, 379
Loctite 609............................................................................ 413 703 100 .........................................375
pulley flange cleaner.............................................................
413 711 809 ......................................... 379
mmr2005-036 369
