Section 07 ELECTRICAL SYSTEM
Subsection 01 (IGNITION SYSTEM)
Now the display shows the engine timing correc-
tion factor that is programmed in the MPEM. In
the following example timing correction factor is
no. 4.
A30E21A
TIMING<1-8>:4
PRESS ANY KEY...
Press any key.
A00A3DA
MODIFY?
YES NO
Select YES using the key ↔ .
Press ENTER.
A30E23A
TIMING<1-8>:TIMING<1-8>:
Select a timing correction factor corresponding to
correction needed.
Example: Timing mark as verified with a timing
lightat3500RPMwastooearlyby2°. The cor-
rection factor programmed is no. 4.
Select correction factor no. 5. This will retard the
timing by 2° because the difference between cor-
rection factor no. 4 and no. 5 is - 2° (passing from
1° to - 1°).
A30E2HA
TIMING<1-8>:5
IGNITION CORRECTION FACTOR
CORRECTION FACTOR
PROGRAMMED IN
MPEM
IGNITION TIMING
CORRECTION
2 3°
3 2°
4
1°
1 0°
5 -1°
6 -2°
7
-3°
8 -4°
Press ENTER.
A30E2GA
2. ENGINE SERIAL#
>1. TIMING ADJUST
3. CALIBRATION
Press ENTER.
A30E24A
TIMING<1-8>:5
PRESS ANY KEY...
The display confirms that correction factor has
been changed to no. 5.
Press any key.
mmr2005-082 289
