Section 03 ENGINES (2-STROKE)
Subsection 01 (277 ENGINE TYPE)
REMOVAL FROM VEHICLE
Remove or disconnect the following then lift en-
gine from vehicle:
– guard
– drive belt
– muffler
– carburetor
– oil injection pump cable
– oil injection inlet line
– impulse line
– electrical connectors
– hood retaining cable
– engine mount nuts.
ENGINE SUPPORT AND MUFFLER
DISASSEMBLY AND ASSEMBLY
Torque the manifold screws no. 16 to 25 N•m
(18 lbf•ft).
Torque the support screws no. 4 to 15 N•m
(133 lbf•in) and nuts no. 1 to 48 N•m(35lbf•ft).
Torque the engine support screws and nut no. 10
to 48 N•m(35lbf•ft).
Apply Loctite 243 (P/N 293 800 060) on threads of
screw no. 2. Torque screws no. 2 retaining the
engine support to engine crankcase to 21 N•m
(15 lbf•ft).
INSTALLATION ON VEHICLE
To install engine on vehicle, reverse removal pro-
cedure. However, pay attention to the following:
– Check tightness of engine mount nuts, and
drive pulley screw.
– After throttle cable installation, check maximum
throttle slide opening.
– Check pulley alignment and drive belt tension.
– Seal exhaust ball joints with Loctite 30542
(P/N 293 800 090).
