Section12TECHNICALDATA
Subsection 02 (VEHICLES)
SKANDIC EXPEDITION TUV
600 HO
SDI
V-1000
4–TEC
ELECTRICAL
Battery
V(Ah)
12 (18) 12 (18)
Headlamp W 60/55 60/55
Taillight and stoplight W 8/27 8/27
Tachometer and speedometer bulbs W N.A. N.A.
Fuel and temperature gauge bulbs W N.A. N.A.
Starter solenoid A 5 5
Fuse
Fuel level sensor A N.A. N.A.
CAPACITIES
Fuel tank L (U.S. gal) 42 (11) 42 (11)
Chaincase/gearbox mL (U.S. oz) 400 (13.5) 400 (13.5)
Cooling system L(U.S.oz) 4.5 (15.2) 4.5 (15.2)
Engine
L(U.S.oz)
N.A. 3.4 (115 )
Engine oil
Reservoir L (U.S. oz) 2.5 (84.5) N.A.
VEHICLE INFORMATIONS
Mass (dry) kg (lb) 325 (717) 345 (761)
Length mm (in) 3150 (124) 3060 (120.5)
Width mm (in) 1185 (46.7) 1185 (46.7)
Height mm (in) 1320 (52) 1320 (52)
Ski stance (carbide to carbide) mm (in) 985 (38.8) 985 (38.8)
Toe-out mm (in) 5 (3/16) 5 (3/16)
Camber mm (in) N.A. N.A.
Frame material Steel Steel
Bottom pan material
High density
polyethylene
High density
polyethylene
Hood material RRIM RRIM
566 mmr2005-057
