Section 09 REAR SUSPENSION
Subsection 05 (TRACK)
TRACK
SERVICE TOOLS
Description Part Number Page
belt tension tester ................................................................ 414 348 200 .........................................512
narrow track cleat installer.................................................... 529 008 500 .........................................511
narrow track cleat installer.................................................... 529 028 800 .........................................514
snowmobile mechanical stand ............................................. 529 020 000 ......................................... 512
track cleat remover............................................................... 529 028 700
................................. 511, 514
TRACK TYPE APPLICATION
Refer to TECHNICAL DATA section.
GENERAL
This section gives guidelines for track removal.
Some components require more detailed disas-
sembly procedures. In these particular cases, re-
fer to the pertaining section in this manual.
INSPECTION
Visually inspect track for:
– cuts and abnormal wear
– broken rods
– broken or missing track cleats.
If track is damaged or rods are broken, replace
track. For damaged or missing cleats, replace by
new ones, using track cleat remover (P/N 529 028
700). Use narrow track cleat installer (P/N 529 008
500).
WARNING
Do not operate a snowmobile with a cut, torn
or damaged track.
REMOVAL
Tun d ra
Remove the following items:
– chaincase cover, sprockets, chain
– muffler
– upper center idler ass'y
– suspension
– end bearing housing
– drive axle seal
– drive axle (outwards from end bearing housing)
– track.
Skandic LT/LT E
Remove the following parts:
– speedometer cable
– muffler
– chaincase cover
– suspension
– drive axle seal
– end bearing housing
– sprockets and chain
– drive axle (toward end bearing housing)
– track.
Skandic WT/SWT/WT LC/SUV/Expedition
TUV
Remove the following parts:
– rear suspension
– muffler.
Drain gearbox.
Remove drive axle then track.
mmr2005-052 511
