Section 02 TROUBLESHOOTING GUIDE

Subsection 06 (SUSPENSION AND TRACK)

SUSPENSION AND TRACK

The following chart is provided to help diagnose the probable source of troubles. It should be used as a

guideline. Some causes or corrections may not apply to a specific model.

Symptom:

SUSPENSION IS TOO LOW.

1. Check condition of springs.

- Springs are broken. Replace springs.

2. Check springs preload.

- Too low spring preload. Increase preload to the recommended position.

3. Check springs.

- Installed springs are too soft. Install optional stiffer springs, refer to Service Bulletin SPRING

REFERENCE ACCORDING TO LOAD.

Symptom: REAR SUSPENSION BOTTOMS OUT.

1. Check condition of springs.

- Springs are broken. Replace springs.

2. Check springs preload.

- Too low spring preload. Increase preload to the recommended position.

3. Check springs.

- Springs installed are too soft. Install optional stiffer springs, refer to Service Bulletin SPRING

REFERENCE ACCORDING TO LOAD.

4. Check the rear shock motion ratio position.

- It is adjusted in soft position. Adjust rear shock motion ratio to firm position.

Symptom: REAR SUSPENSION IS TOO STIFF.

1. Check rear spring preload.

- Too much preload. Adjust to a softer position.

2. Check springs.

- Springs installed are too stiff. Install optional softer springs, refer to Service Bulletin SPRING

REFERENCE ACCORDING TO LOAD.

3. Check the rear shock motion ratio position.

- It is adjusted in firm position. Adjust rear shock motion ratio to soft position.

4. Check track tension.

- Track is too tight. Adjust.

5. Check if axles are properly lubricated.

- Improper lubrication and/or contaminated grease (sticky oil sludge). Clean and/or lubricate.

Symptom: WHEN HANDLEBAR IS TURNED, SNOWMOBILE UNDERSTEERS.

1. Check ski runner condition.

- Worn ski runners. Replace.

2. Check ski spring preload.

- Insufficient ski pressure on the ground. Increase spring preload.
