Section 02 TROUBLESHOOTING
Subsection 01 (ENGINE)
SYMPTOM ENGINE EQUIPPED WITH RAVE. ENGINE HESITATES AT LOW OR MID-SPEED AND REACHES
MAXIMUM PERFORMANCE ONLY AFTER A WHILE.
CONDITION NORMAL USE.
1. Check RAVE valve spring(s).
a. Spring tension is too low or spring(s) is (are) broken.
Replace.
2. Check RAVE valve cover red adjustment screws.
a. Adjustment screw(s) is (are) too loose.
Adjust according to ASSEMBLY PROCEDURE in appropriate engine subsections.
TEST/INSPECTION
3. Check RAVE valve movement (RAVE movement indicator P/N 861 725 800).
a. Valve(s) is (are) stuck in open position.
Clean.
SYMPTOM REWIND STARTER ROPE DOES NOT REWIND.
CONDITION NORMAL USE.
TEST/INSPECTION 1. Check rewind spring.
a. Broken spring.
Replace spring.
SYMPTOM REWIND STARTER PAWL DOES NOT ENGAGE.
CONDITION NORMAL USE.
1. Check stopper spring.
a. Broken stopper spring.
Replace.
2. Check pawl and pawl lock.
a. Pawl and pawl lock have stuck together because of heat.
Replace.
TEST/INSPECTION
3. Check pawl and rope sheave.
a. Pawl and rope sheave have stuck together because of heat.
Replace.
18 mmr2005-063
