Section 04 ENGINE MANAGEMENT (SDI)
Subsection 02 (DIAGNOSTIC PROCEDURE)
PCODE EMS PILOT LAMP BEEPER DESCRIPTION
P0118 BLINK OFF
Engine temperature sensor voltage too high.
P0116 BLINK OFF
Engine temperature sensor functional problem.
P0112 BLINK OFF
Air temperature sensor voltage too low.
P0113 BLINK OFF
Air temperature sensor voltage too high.
P0111 BLINK OFF
Air temperature sensor functional problem.
P0078 BLINK OFF
E-RAVE actuator functional problem.
P0107 BLINK OFF
Air pressure sensor voltage too low.
P0108 BLINK OFF
Air pressure sensor voltage too high.
P0600 BLINK OFF
E-RAVE actuator communication problem.
P0608 BLINK OFF Sensor's power supply voltage too low.
P0608 BLINK OFF Sensor's power supply voltage too high.
P0232 BLINK OFF
Fuel pump shorted to battery.
P0231 BLINK OFF
Fuel pump open circuit or shorted to ground.
P0080 BLINK OFF
RAVE
®
solenoid shorted to battery.
P0079 BLINK OFF
RAVE
®
solenoid open circuit or shorted to ground.
P0326 BLINK OFF
Knock sensor signal below minimum noise.
P1502 BLINK OFF TOPS functional problem.
P0351 BLINK
OFF
No ignition output cylinder # 1
(MAG for 2 cyl. engine).
P0352 BLINK OFF
No ignition output cylinder # 2
(PTO for 2 cyl. engine).
P0262 BLINK OFF
Injector cyl. # 1 OR outer MAG injector
(2 cyl.), shorted to battery.
P0261 BLINK OFF
Injector cyl. # 1 OR outer MAG injector
(2 cyl.), open circuit or shorted to ground.
P0265 BLINK OFF
Injector cyl. # 2 OR outer PTO injector
(2 cyl.), shorted to battery.
P0264 BLINK
OFF
Injector cyl. # 2 OR outer PTO injector
(2 cyl.), open circuit or shorted to ground.
P0268 BLINK
OFF
Injector cyl. # 3 OR inner MAG injector
(2 cyl.), shorted to battery.
P0267 BLINK
OFF
Injector cyl. # 3 OR inner MAG injector
(2 cyl.), open circuit or shorted to ground.
P0271 BLINK
OFF Inner PTO injector shorted to battery.
P0270 BLINK
OFF Inner PTO injector open circuit or shorted to ground.
P0122 BLINK
OFF
Throttle position sensor voltage too low.
P0123 BLINK
OFF
Throttle position sensor voltage too high.
mmr2004-125 131
