Section 12 TECHNICAL DATA
Subsection 01 (FAN COOLED MODELS)
FAN COOLED MODELS
GSX/GTX/MX Z
EXPEDITION/SUMMIT/
GSX/GTX/MX Z
MODEL
380 F 550 F
ENGINE
Engine type 377 552
Number of cylinder 2
Bore Standard mm (in) 62 (2.441) 76 (2.992)
Stroke mm (in) 61.00 (2.402)
Displacement cm
3
(in
3
) 368.30 (22.475) 553.40 (33.771)
Compression ratio 11.2 ± 0.5 9.6 ± 0.5
Maximum power engine speed (1) ± 100 RPM 7000
1
st
Semi-trapezoidal
Piston ring type
2
nd
Rectangular
New mm (in) 0.20 to 0.35 (.008 to .0138) 0.40 to 0.55 (.016 to .022)
Ring end gap
Wear limit mm (in) 1.0 (.039)
New mm (in) 0.040 to 0.110 (.0016 to .0043) 0.04 to 0.08 (.0016 to .0030)
Ring/piston groove clearance
Wear limit mm (in) 0.2 (.0079)
New mm (in) 0.070 ± 0.016 (.0028 ± .0006) 0.147 ± 0.026 (.0058 ± .0010)
Piston/cylinder wall clearance
Wear limit mm (in) 0.2 (.0079)
Maximum crankshaft end play (2) New mm (in) 0.3 (.012)
Maximum crankshaft deflection at PTO Wear limit mm (in) 0.06 (.0024)
New mm (in) 0.200 to 0.527 (.0079 to .0207)
Connecting rod big end axial paly
Wear limit mm (in) 1.2 (.0472)
ELECTRICAL
Magneto generator output 340 W
Ignition type CDI
Make and type NGK BR9ES (6)
Spark plug
Gap mm (in) 0.40 to 0.50 (.016 to .020)
Ignition timing BTDC (3) mm (in) 2.79 (.110) 2.77 (.109)
Trigger coil (4) 160 to 180
Low speed 6.3
Generating coil (4)
High speed 7.7
Lighting coil (4) 0.145 to 0.175
Primary N.A.
High tension coil (4)
Secondary N.A.
Battery 12 V, 18 A•h (if applicable)
Headlamp W 60/55 (H4)
Taillight and stoplight W 8/27
Tachometer and speedometer bulbs W 2x3
Fuel and temperature gauge bulbs W N.A.
Starter solenoid A 30 (if applicable)
Fuse
Fuel level sensor A N.A.
mmr2005-101 465
