Section 06 DRIVE SYSTEM
Subsection 02 (DRIVE PULLEY)
DRIVE PULLEY
SERVICE TOOLS
Description Part Number Page
bushing remover/installer .....................................................
529 031 200 .........................................194
drive pulley holder ................................................................
529 035 674
.................................191, 198
drive pulley puller..................................................................
529 022 400 .........................................191
slider shoe fork..................................................................... 529 005 500
.................................192, 197
sliding half bushing remover/installer ...................................
529 035 931 ................................. 194–195
spring compressor................................................................
529 035 524
................. 192, 194–195, 197
SERVICE PRODUCTS
Description Part Number Page
Loctite 271 (red) ...................................................................
293 800 005 ......................................... 195
Loctite 609............................................................................ 413 703 100 .................................195–197
pulley flange cleaner.............................................................
413 711 809
................................. 193, 195
mmr2005-132 189
