Section 05 ENGINE MANAGEMENT (POWER TEK)
Subsection 03 (COMPONENT INSPECTION, REPLACEMENT AND ADJUSTMENT)
DESS Post Verification — Tether
Cord Cap Removed
Connect test probes to switch BLACK/GREEN and
BLACK/WHITE wires. Measure resistance, there
should be NO continuity (open circuit).
Connect one test probe to the WHITE/GREY wire
and the other test probe to the switch top termi-
nal. Measure resistance, it must be close to 0
ohm.
Connect one test probe to the BLACK/GREEN
wire and the other test probe to the switch ring.
Measure resistance, it must be close to 0 ohm.
DESS Post Verification — Tether
Cord Cap on DESS Post
Connect test probes to switch BLACK/GREEN
and BLACK/WHITE wires. Measure resistance, it
must be close to 0 ohm.
mmr2005-107 229
