Section 06 ENGINE MANAGEMENT (4-TEC)
Subsection 03 (COMPONENT INSPECTION AND ADJUSTMENT)
COMPONENT INSPECTION AND
ADJUSTMENT
SERVICE TOOLS
Description Part Number Page
Fluke 111.............................................................................. 529 035 868 ......................................... 313
fuel pump wrench ................................................................
529 035 899 ................................. 321–322
pressure gauge.....................................................................
529 035 591 ......................................... 319
supply cable..........................................................................
529 035 869 ......................................... 338
tachometer ........................................................................... 529 014 500 ......................................... 315
VCK (vehicle communication Kit)..........................................
529 035 981
................................. 311, 320
wrench.................................................................................. 529 035 603 ......................................... 320
SERVICE PRODUCTS
Description Part Number Page
silicone lubricant................................................................... 293 600 041 ......................................... 338
GENERAL
Engine problems are not necessarily related to the
electronic fuel injection system.
It is important to ensure that the mechanical in-
tegrity of the engine/propulsion system is present:
– good transmission system operation
– good engine compression and properly operat-
ing mechanical components, no leaks etc.
– fuel pump connection and fuel lines without
leaks.
Check the chart in TROUBLESHOOTING section
to have an overview of problems and suggested
solutions.
When replacing a component, always check its
operation after installation.
FUEL SYSTEM
WARNING
The fuel system of a fuel injection system
holds much more pressure than on a carbu-
reted snowmobile. Prior to disconnecting
a hose or to removing a component from
the fuel system, follow the recommenda-
tion described here. Pay attention that some
hoses may have more than one clamp at their
ends. Ensure to reinstall the same quantity
of clamps at assembly.
– Use the VCK (vehicle communication Kit)
(P/N 529 035 981) to release the fuel pressure
in the system. Look in the Activation section
of the software B.U.D.S.
mmr2005-032 311
