Section12TECHNICALDATA
Subsection 01 (ENGINES)
SKANDIC
LT WT/SWT/SUV SUV/WT LC
ENGINE TYPE
443 552 593
FUEL SYSTEM
Carburetor type PTO/MAG 1 x VM 32-306 2 x VM 34-614 2xVM38-449
Main jet PTO/MAG 180 190 330
Needle jet 159 O-0 159 P-0 480 P-9
Pilot jet 50 40 40
Needle identification — clip position PTO/MAG 6DGY12-3 6DH4-2 6DGL24-3
Slide cut-away 3 2.5 2.5
Float adjustment mm (in)
23.9 (.941)
± 1 (.040)
23.9 (.941)
± 1 (.040)
18.1 (.710)
± 1 (.040)
Air or pilot screw adjustment ±1/16turn 1 1-1/2 2
Idle speed ± 200 RPM 1800 1650 1900
Type Regular unleaded Regular unleaded Regular unleaded
Gas
Octane number
North America:
87 (R+M)/2
Elsewhere: 91 RON
North America:
87 (R+M)/2
Elsewhere: 91 RON
North America:
87 (R+M)/2
Elsewhere: 91 RON
Gas/oil ratio Injection Injection Injection
COOLING SYSTEM
Type Axial Fan Axial fan Liquid
Deflection mm (in) 9 - 10 (.35 - .39) 9 - 10 (.35 - .39) N.A.
Axial fan belt adjustment
Force kg (lbf) 5 (11) 5 (11) N.A.
Coolant N.A. N.A. (8)
Thermostat opening temperature
°C(°F)
N.A. N.A. 42 (108)
Radiator cap opening pressure kPa
(PSI)
N.A. N.A. 100 (14.5)
TIGHTENING TORQUE (engine cold)
Drive pulley retaining screw
N•m
(lbf•ft)
(5) (5) (5)
Exhaust manifold nuts or bolts
N•m
(lbf•ft)
22 (16) 22 (16) 23 (17)
Magnetoringnut
N•m
(lbf•ft)
105 (77) 105 (77) 125 (92)
M6
N•m
(lbf•
in)
9 (6.5) N.A. 9(6.5)
Crankcase nuts or screws
M8
N•m
(lbf•ft)
22 (16) 27 (20) 29 (21)
Crankcase/engine support nuts or screws
N•m
(lbf•ft)
39 (29) 40 (30) 35 (26)
Cylinder head screws or nuts
N•m
(lbf•ft)
22 (16) 22 (16) 29 (21)
Crankcase/cylinder nuts or screws
N•m
(lbf•ft)
N.A. N.A. 29 (21)
Axial fan shaft nut
N•m
(lbf•ft)
48 (35) 48 (35) N.A.
552 mmr2005-057
