6.10. prefer
Данная команда отмечает текущий NTP-сервер как предпочтительный. При прочих равных
условиях данный NTP-сервер будет выбран для синхронизации среди всех рабочих NTP-
серверов.
Использование отрицательной формы команды устанавливает значение по умолчанию.
Синтаксис
[no] prefer
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-ntp-vrf-peer-ipv4
config-ntp-vrf-server-ipv4
Пример
0/ME5100:example_router01(config)# ntp vrf default
0/ME5100:example_router01(config-vrf)# server ipv4 192.168.16.36
0/ME5100:example_router01(config-ipv4)# prefer
6.11. server ipv4
Данная команда используется для создания NTP-сервера и перехода в командный режим
config-ntp-vrf-server-ipv4. Маршрутизатор работает с указанным NTP-сервером в режиме
односторонней активности. В данном режиме локальные часы маршрутизатора могут
синхронизироваться с удаленным NTP сервером.
Использование отрицательной формы команды удаляет заданный NTP-сервер.
Синтаксис
[no] ntp server ipv4 IPv4_ADDR
Параметры
• IPv4_ADDR — IPv4-адрес сервера;
Необходимый уровень привилегий
p10
Командный режим
config-ntp-vrf
79
