![Eltex ME5200 [38/670] Show processes cpu](/views2/1569351/page38/bg26.png)
0/ME5100:example_router01# show privilege
Mon May 8 14:58:53 2017
Current privilege level is 15
2.13. show processes cpu
Данная команда показывает потребление процессорного времени (нагрузку на
центральный процессор устройства и модулей) внутренними процессами устройства.
Синтаксис
show processes cpu
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show processes cpu
Wed Aug 23 17:42:02 2017
Ê CPU utilization per board:
Ê 1Min 5Min 15Min Unit
Ê -------- -------- -------- ---------
Ê 1.08% 1.33% 1.03% 0/ME5100
Ê CPU utilization per process:
Ê 1Min 5Min 15Min Unit Process
Ê -------- -------- -------- --------- --------
Ê 0.88% 0.92% 0.90% 0/ME5100 pp-manager
Ê 0.10% 0.11% 0.10% 0/ME5100 syslog-ng
Ê 0.02% - - 0/ME5100 clish(192.168.16.113)
Ê 0.01% 0.01% 0.01% 0/ME5100 dcsi
Ê<...>
2.14. show processes memory
Данная команда показывает потребление оперативной памяти внутренними процессами
устройства.
Синтаксис
show processes memory
