необходимо использовать команды maximum-paths и max-advertised-paths.
Отрицательная форма команды выключает поддержку Additional Paths.
Синтаксис
additional-paths { both | disable | inherit | receive | send }
no additional-paths
Параметры
• both — включает прием и анонсирование дополнительных путей;
• disable — выключает функцию Additional Paths;
• inherit — в конфигурации сессии или группы соседей наследуется значение из router
bgp afi/safi;
• receive — включает только прием дополнительных путей;
• send — включает только анонсирование дополнительных путей.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-address-family-ipv4-unicast
config-router-bgp-address-family-ipv6-unicast
config-router-bgp-neighbor-address-family-ipv4-unicast
config-router-bgp-neighbor-address-family-ipv6-unicast
config-router-bgp-peer-group-address-family-ipv4-unicast
config-router-bgp-peer-group-address-family-ipv6-unicast
config-router-bgp-vrf-address-family-ipv4-unicast
config-router-bgp-vrf-address-family-ipv6-unicast
config-router-bgp-vrf-neighbor-address-family-ipv4-unicast
config-router-bgp-vrf-neighbor-address-family-ipv6-unicast
config-router-bgp-vrf-peer-group-address-family-ipv4-unicast
config-router-bgp-vrf-peer-group-address-family-ipv6-unicast
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# additional-paths both
0/ME5100:example_router01(config-unicast)# no additional-paths
0/ME5100:example_router01(config-unicast)#
13.3. address-family
Команда включает обмен маршрутами заданного семейства (AFI/SAFI) для указанного
соседа (neighbor), группы (peer group) и переходит в режим настройки параметров этого
семейства. Команда может быть использована и для настройки глобальных параметров
258
