Командный режим
config-router-ospfv2-redistribution
config-router-ospfv2-vrf-redistribution
config-router-ospfv3-redistribution
config-router-ospfv3-vrf-redistribution
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# redistribution local local
0/ME5100:example_router01(config-local)# metric-conversion same
0/ME5100:example_router01(config-local)#
11.39. metric-type
Команда позволяет задать тип external маршрута при редистрибуции из другого протокола
маршрутизации.
Отрицательная форма команды возвращает значение по умолчанию (ospf-type2-external).
Синтаксис
metric-type { ospf-type1-external | ospf-type2-external }
no metric-type
Параметры
• ospf-type1-external — OSPF External Type1;
• ospf-type2-external — OSPF External Type2.
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-redistribution
config-router-ospfv2-vrf-redistribution
config-router-ospfv3-redistribution
config-router-ospfv3-vrf-redistribution
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# redistribution isis ISIS
0/ME5100:example_router01(config-isis)# metric-type ospf-type1-external
0/ME5100:example_router01(config-isis)# no metric-type
0/ME5100:example_router01(config-isis)#
156
