![Eltex ME5200 [251/670] Redistribute address](/views2/1569351/page251/bgfb.png)
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# address-family ipv4 unicast redistribution bgp
RULE
0/ME5100:example_router01(config-bgp)# redistribute disable
0/ME5100:example_router01(config-bgp)#
12.60. redistribute-address
Данная команда позволяет создать в конфигурации правило для редистрибуции
определенного маршрута второго уровня IS-IS (IS-IS Level 2) в первый уровень (IS-IS Level 1).
Отрицательная форма команды удаляет данное правило.
Синтаксис
[no] redistribute-address IPv4_PREFIX_FORMAT
Параметры
• IPv4_PREFIX_FORMAT — маршрут IS-IS Level 2 в формате IPv4-префикса.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis
config-router-isis-vrf
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# redistribute-address 10.0.0.0/8
0/ME5100:example_router01(config-isis)#
12.61. redistribution
Данная команда создает правило правило для передачи маршрутов определенного
происхождения (другие протоколы маршрутизации, статические маршруты и т.п.) в
процесс маршрутизации IS-IS. Механизм такой передачи также называется
редистрибуцией.
Отрицательная форма команды удаляет определенное правило из конфигурации.
Синтаксис
[no] redistribution { bgp | connected | ospf | local | static } STRING
Параметры
• bgp, connected, ospf, local, static — протокол, из которого будет происходить
редистрибуция;
230
