0/ME5100:example_router01# show system resources cpu
Thu Feb 7 15:06:31 2019
Ê CPU resources for ME5100
Ê CPU Number Last 5 sec Last 1 min Last 5 min
Ê ----------- ----------- ----------- -----------
Ê CPU 0 4.68% 5.03% 5.18%
Ê CPU 1 3.60% 3.88% 3.92%
Ê CPU 2 0.00% 0.12% 0.07%
Ê CPU 3 0.36% 1.87% 3.88%
Ê CPU 4 1.26% 4.86% 4.08%
Ê CPU 5 0.00% 1.83% 0.90%
Ê CPU 6 2.34% 2.96% 1.45%
Ê CPU 7 3.97% 3.86% 3.39%
0/ME5100:example_router01#
2.22. show version
Данная команда выводит полный номер версии работающего в данный момент на
устройстве программного обеспечения.
Синтаксис
show version
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show version
Mon May 8 15:28:27 2017
Eltex ME5100 carrier router running Network OS for ME5k ver. 1.5.0.205R (04-May-2017
06:38:47)
2.23. ssh
Данная команда используется для подключения к удаленному узлу по протоколу SSH.
23
