Eltex ME5100 [470/670] Show pim topology
![Eltex ME5100 [470/670] Show pim topology](/views2/1569351/page470/bg1d6.png)
0/ME5100:example_router01# show pim summary
Tue Sep 12 11:18:31 2017
Ê PIM IPv4 State Counters
Ê Current Maximum Warning-
threshold
Ê Groups (*,G) 1 0 0
Ê Groups (S,G) 0 0 0
Ê Groups (*,G,I) 1 0 0
Ê Groups (S,G,I) 0 0 0
Ê Null Register messages received: 0
Ê Number diff source addr known: 0
Ê Number diff Rendezvous Point: 2
18.21. show pim topology
Вывод PIM топологии
Синтаксис
show pim topology [ detail | GROUP [ detail ] ]
Параметры
• GROUP — вывод записей по указанной широковещательной группе;
• detail — детализированный вывод.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show pim topology
Tue Sep 12 10:45:22 2017
Ê IP PIM Multicast Topology Table
Ê Entry state: (*/S,G)[RPT/SPT] Mode, Protocol, Uptime, Info
Ê Interface state: Name, Uptime, Fwd, Info
Ê (*, 225.54.205.135) asm, Up: 15h57m21s, RP: 23.23.23.23 is not local (config)
Ê JP: joined(17h05m46s), RPF: Tengigabitethernet 0/0/12, nexthop: 100.99.133.33
isis, prefix: 23.23.23.23/32
Ê te 0/0/7 asm, Up: 01h08m42s is local
18.22. show pim traffic
Вывод счётчиков pim-сообщений всех типов по всем интерфейсам.
449
