0/ME5100:example_router01# show debug
Mon May 8 14:50:11 2017
Ê System Subsystem
Ê ---------------- ----------------------
Ê pp-mgr arp
Ê cmd
Ê general
Ê l2
Ê mpls
Ê interfaces
Ê egress-obj
Ê routes
Ê ip-addrs
Ê sfp-monitoring
Ê sync
Ê vpn
Ê hw-api
Ê if-mgr cmd
Ê general
Ê interfaces
Ê sync-nbase
Ê sync-os
Ê sync-phys
Ê sync-mapper
Ê sync-neighbor
0/ME5100:example_router01#
2.12. show privilege
Данная команда показывает уровень привилегий пользователя в текущей сессии CLI.
Синтаксис
show privilege
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
16
