Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show igmp groups
Tue Sep 12 16:09:27 2017
Ê IGMP Connected Group Membership
Ê Group Address Interface Uptime Expires Last
Reporter
Ê ------------------------ ------------------------ ---------- ----------
--------------
Ê 225.54.205.135 te 0/0/7 06h32m46s 00h04m00s
192.168.10.100
19.10. show igmp interface
Команда отображает информацию о состоянии протокола IGMP на интерфейсах.
Синтаксис
show igmp interface [ detail ]
Параметры
• detail — Развернутый вывод по каждому интерфейсу.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show igmp interface
Tue Sep 12 16:42:50 2017
Ê Tengigabitethernet 0/0/7 IGMP status is up
Ê IGMP is enabled on interface
Ê Current IGMP version is 3
Ê IGMP query interval is 125 is seconds
Ê IGMP querier timeout is 0 is seconds
Ê IGMP max query response time is 100 is seconds
Ê Last member query response interval is 10 is seconds
Ê IGMP activity: 3 joins, 2715 leaves
Ê IGMP querying router is 192.168.10.1 (this system)
457
