config-router-ospfv3-area-interface
config-router-ospfv3-virtual-interface
config-router-ospfv3-vrf-area-interface
config-router-ospfv3-vrf-virtual-interface
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# area 0.0.0.0
0/ME5100:example_router01(config-area)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# restart-helper-strict-lsa-check
disable
0/ME5100:example_router01(config-tengigabitethernet)#
11.59. retransmit-interval
Данная команда позволяет установить в конфигурации интервал, определяющий, сколько
пройдет времени между получением от OSPF-соседа LSA и отправкой её другим соседям.
Отрицательная форма команды возвращает значение по умолчанию (5).
Синтаксис
retransmit-interval SECONDS
no retransmit-interval
Параметры
• SECONDS — значение таймера в секундах (1..1800).
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-area-interface
config-router-ospfv2-virtual-interface
config-router-ospfv2-vrf-area-interface
config-router-ospfv2-vrf-virtual-interface
config-router-ospfv3-area-interface
config-router-ospfv3-virtual-interface
config-router-ospfv3-vrf-area-interface
config-router-ospfv3-vrf-virtual-interface
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# area 0.0.0.0
0/ME5100:example_router01(config-area)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# retransmit-interval 10
0/ME5100:example_router01(config-tengigabitethernet)#
170
