Eltex ME5100 [144/670] Настройка статической маршрутизации
![Eltex ME5100 [144/670] Настройка статической маршрутизации](/views2/1569351/page144/bg90.png)
10. НАСТРОЙКА СТАТИЧЕСКОЙ
МАРШРУТИЗАЦИИ
Статическая маршрутизация — это механизм, при помощи которого в системе можно
вручную создавать, удалять и модифицировать IP-маршруты. Статические маршруты могут
быть заданы как в глобальной таблице маршрутизации, так и внутри VRF.
10.1. action
Задание действия для пакетов для данного маршрута при маршрутизации трафика.
Отрицательная форма команды устанавливает значение по умолчанию (forward).
Синтаксис
action { discard | forward | local | reject}
no action
Параметры
• discard — отбросить пакеты, редистрибуция разрешена;
• forward — отправить пакеты по маршруту;
• local — отбросить пакеты, редистрибуция запрещена;
• reject — не инсталлировать маршрут.
Необходимый уровень привилегий
p10
Командный режим
config-router-static-destination-interface
Пример
0/ME5100:example_router01(config)# router static
0/ME5100:example_router01(config-static)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# destination 40.10.0.0/16 40.10.0.1
0/ME5100:example_router01(config-destination)# interface tengigabitethernet 0/0/7
0/ME5100:example_router01(config-tengigabitethernet)# action reject
0/ME5100:example_router01(config-tengigabitethernet)#
10.2. address-family
Команда производит переход в режим настройки маршрутов соответствующего семейства
протоколов (AFI/SAFI).
Отрицательная форма удаляет все статические маршруты в указанной паре AFI/SAFI.
123
