Eltex ME5100 [481/670] Sources limit
![Eltex ME5100 [481/670] Sources limit](/views2/1569351/page481/bg1e1.png)
0/ME5100:example_router01# show igmp traffic
Tue Sep 12 16:56:17 2017
Ê IGMP Traffic Counter
Ê Number of queries Recived and Processed:
Ê Queries: 0
Ê Reports: 1402
Ê Leaves: 0
Ê Total: 1402
Ê Number of queries Filtered:
Ê Protocol Version failed: 0
Ê Query version failed: 0
Ê Limit failed: 0
Ê Group source failed: 0
Ê Link local failed: 2751
Ê Other reason failed: 0
Ê Total failed: 2751
Ê Number of queries Bad:
Ê Checksum: 0
Ê Router alert: 0
Ê SSM range: 4
Ê Other reason: 2
Ê Total: 6
Ê Total number of queries sent: 691
19.14. sources-limit
Команда задает максимальное количество источников для заданного интерфейса.
Отрицательная форма команды снимает ограничение, устанавливает значение по
умолчанию (0).
Синтаксис
sources-limit INTEGER
no sources-limit
Параметры
• INTEGER — Максимальное количество записей. Диапазон допустимых значений:
0..4294967295
Необходимый уровень привилегий
p10
Командный режим
config-router-igmp-interface
Пример
460
