0/ME5100:example_router01(config)# no lacp
0/ME5100:example_router01(config)#
24.8. lacp redundancy-groups redundancy-group
Номер группы избыточности (MC-LAG). Должен быть одинаковым между двумя
устройствами, обслуживающими MC-LAG.
Отрицательная форма команды удаляет группу избыточности.
Синтаксис
[no] lacp redundancy-groups redundancy-group (0-4294967295)
Параметры
• (0-4294967295) — Номер группы избыточности
Необходимый уровень привилегий
p10
Командный режим
configure
Пример
0/ME5100:example_router01(config)# lacp redundancy-groups redundancy-group 10
0/ME5100:example_router01(config-redundancy-group)#
24.9. lacp system mac-address
Установка системного mac-адреса для LACPDU.
Отрицательная форма команды устанавливает значение по умолчанию (системный MAC-
адрес).
Синтаксис
lacp system mac-address MAC_ADDR
no lacp system mac-address
Параметры
• MAC_ADDR — MAC-адрес в формате XX:XX:XX:XX:XX:XX.
Необходимый уровень привилегий
p10
Командный режим
configure
522
