config-router-isis-vrf-address-family-ipv4-unicast-lfa-filter
config-router-isis-vrf-address-family-ipv6-unicast-lfa-filter
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# lfa filter FILTER
0/ME5100:example_router01(config-filter)# address-prefix 10.0.0.0/8
0/ME5100:example_router01(config-filter)#
12.4. admin-tag
В режиме конфигурации интерфейса, участвующего в IS-IS процессе маршрутизации (config-
router-isis-interface и config-router-isis-vrf-interface) данная команда создает в конфигурации
правило для анонсирования данного interface с определенным tag.
В режиме конфигурации правила для summary-address (config-router-isis-summary-address и
config-router-isis-vrf-summary-address) данная команда устанавливает определенный tag для
суммарного маршрута.
В режиме конфигурации интерфейса, участвующего в IS-IS процессе маршрутизации
отрицательная форма команды удаляет из конфигурации данное правило.
В режиме конфигурации правила для summary-address (config-router-isis-summary-address и
config-router-isis-vrf-summary-address) отрицательная форма команды удаляет из
конфигурации данный tag.
Синтаксис
admin-tag TAG
no admin-tag
Параметры
• TAG — tag, с которым будет анонсироваться данный интерфейс.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-interface
config-router-isis-summary-address
config-router-isis-vrf-interface
config-router-isis-vrf-summary-address
Пример
192
