Отрицательная форма команды возвращает значение по умолчанию (1).
Синтаксис
maximum-paths INTEGER
no maximum-paths
Параметры
• INTEGER — количество маршрутов. Диапазон допустимых значений: 1..8.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-address-family-ipv4-unicast
config-router-bgp-address-family-ipv6-unicast
config-router-bgp-vrf-address-family-ipv4-unicast
config-router-bgp-vrf-address-family-ipv6-unicast
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# maximum-paths 8
0/ME5100:example_router01(config-unicast)# no maximum-paths
13.56. neighbor
Команда создает BGP соседа (сессию) с заданным IP адресом и переходит в режим
конфигурации данного соседа (config-router-bgp-neighbor).
Отрицательная форма команды удаляет указанного соседа и всю связанную конфигурацию.
Синтаксис
[no] neighbor { IPv4_ADDRESS_FORMAT | IPv6_ADDRESS_FORMAT }
Параметры
• IPv4_ADDRESS_FORMAT — значение идентификатора соседа в формате IPv4 адреса.
• IPv6_ADDRESS_FORMAT — значение идентификатора соседа в формате IPv6 адреса.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp
config-router-bgp-vrf
Пример
294
