9. НАСТРОЙКА VRF
Данный раздел посвящен настройке экземпляров VRF (Virtual Routing and Forwarding).
9.1. description
Данная команда позволяет задать в конфигурации описание для текущего VRF.
Отрицательная форма команды удаляет данное описание из конфигурации.
Синтаксис
description STRING
no description
Параметры
• STRING — текстовое представление описания.
Необходимый уровень привилегий
p10
Командный режим
config-vrf
Пример
0/ME5100:example_router01(config)# vrf test
0/ME5100:example_router01(config-vrf)# description test
0/ME5100:example_router01(config-vrf)#
9.2. export route-target
Данная команда позволяет задать в конфигурации, какой Route Target будет использоваться
для экспорта в данном VRF.
Отрицательная форма команды удаляет данный Route Target для экспорта в данном VRF.
Синтаксис
[no] export route-target RT_FORMAT
Параметеры
• RT_FORMAT — значение Route Target в формате AS:nn, либо IPv4:nn, где:
◦ AS - значение в формате Autonomous System;
◦ IPv4 - значение в формате IPv4-адреса;
◦ nn - число.
Необходимый уровень привилегий
118
