Команда не содержит параметроы.
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-area
config-router-ospfv2-vrf-area
config-router-ospfv3-area
config-router-ospfv3-vrf-area
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# area 0.0.0.1
0/ME5100:example_router01(config-area)# nssa
0/ME5100:example_router01(config-area)#
11.45. nssa default-information-originate
Данная команда включает анонсирование маршрута по умолчанию в заданной NSSA
области.
Отрицательная форма команды отключает анонсирование маршрута по умолчанию.
Синтаксис
[no] nssa default-information-originate
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-area
config-router-ospfv2-vrf-area
config-router-ospfv3-area
config-router-ospfv3-vrf-area
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# area 0.0.0.1
0/ME5100:example_router01(config-area)# nssa default-information-originate
0/ME5100:example_router01(config-area)#
160
