Командный режим
config
Пример
0/ME5100:example_router01(config)# telnet server vrf default
0/ME5100:example_router01(config-vrf)#
IMPORTANT
В целях обеспечения безопасности устройства и ограничения
возможности несанкционированного доступа не рекомендуется
запускать Telnet- и SSH-серверы в тех VRF, для которых это не требуется
явно политикой доступа к устройству. Рекомендуется осуществлять
управление устройством в специально выделенном для этих целей
VRF.
5.40. timeout
Данная команда задает время ожидания ответа от указанного RADIUS-сервера, в секундах.
Отрицательная форма команды устанавливает значение по умолчанию (равное глобальной
настройке radius-server timeout).
Синтаксис
timeout SECS
[no] timeout
Параметры
• SECS — время ожидания ответа от сервера, принимает значение 1..30 сек.
Командный режим
config-aaa-radius-server-host
Пример
0/ME5100:example_router01(config)# radius-server host 192.168.16.245 vrf mgmt-intf
0/ME5100:example_router01(config-host)# timeout 20
5.41. user
Данная команда создает в конфигурации устройства учетную запись локального
пользователя и осуществляет переход в режим настройки параметров этой учетной записи
(config-user).
Отрицательная форма команды удаляет учетную запись локального пользователя из
конфигурации устройства.
72
