(MTU) Attachment circuit (AC).
Отрицательная форма команды возвращает поведение по умолчанию, при несовпадении
MTU pseudowire не поднимается..
Синтаксис
[no] ignore mtu-mismatch
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-l2vpn-bridge-domain-autodiscovery-bgp
config-l2vpn-bridge-domain-pw
config-l2vpn-bridge-domain-pw-backup-pw
config-l2vpn-bridge-domain-vfi-pw
config-l2vpn-bridge-domain-vfi-pw-backup-pw
config-l2vpn-xconnect-group-p2p-autodiscovery-bgp
config-l2vpn-xconnect-group-p2p-pw
config-l2vpn-xconnect-group-p2p-pw-backup-pw
Пример
0/ME5100:example_router01(config)# l2vpn bridge-domain test
0/ME5100:example_router01(config-bridge-domain)# pw 172.16.0.2 12
0/ME5100:example_router01(config-pw)# ignore mtu-mismatch
0/ME5100:example_router01(config-pw)#
15.13. import
Данная команда позволяет установить в конфигурации заданный RT на импорт.
Отрицательная форма команды удаляет данный элемент из конфигурации.
Синтаксис
import
no import
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
394
