Отрицательная форма команды удаляет из конфигурации данный таймер.
Синтаксис
graceful-restart max-grace-period SECONDS
[no] graceful-restart max-grace-period
Параметры
• SECONDS — значение таймера max-grace-period в секундах (1..1800).
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-area-interface
config-router-ospfv2-virtual-interface
config-router-ospfv2-vrf-area-interface
config-router-ospfv2-vrf-virtual-interface
config-router-ospfv3-area-interface
config-router-ospfv3-virtual-interface
config-router-ospfv3-vrf-area-interface
config-router-ospfv3-vrf-virtual-interface
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# area 0.0.0.0
0/ME5100:example_router01(config-area)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# graceful-restart max-grace-
period 600
0/ME5100:example_router01(config-tengigabitethernet)#
11.19. graceful-restart unplanned
Данная команда включает механизм незапланированного OSPF Graceful Restart.
Отрицательная форма команды выключает данный механизм.
Синтаксис
[no] graceful-restart unplanned
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2
141
