0/ME5100:EOS(config)# hostname example_router01
4.5. hw-module location
Данная команда позволяет перейти в режим настройки различных параметров
аппаратного модуля в составе устройства (config-hw-module-location).
Синтаксис
hw-module location LOCATION
Параметры
• LOCATION — местоположение аппаратного модуля в системе. Имеет формат
<UNIT>/<SLOT>, где <UNIT> - номер устройства в кластере устройств, а <SLOT> - номер
модуля в составе устройства. Для ME5100 в одиночном режиме в качестве данного
параметра следует указывать 0/0.
Необходимый уровень привилегий
p15
Командный режим
config
Пример
0/ME5100:example_router01(config)# hw-module location 0/0
0/ME5100:example_router01(config-location)#
4.6. load-balancing hash-fields
Данная команда позволяет указать, какие поля в пакетах проходящего трафика будут
учитываться при балансировке этого трафика по параллельным путям.
К такой балансировке относится балансировка по составным интерфейсам группы
агрегации каналов (Bundle-ether) и балансировка по путям equal-cost multipath (ECMP).
Можно включать балансировку по нескольким полям, по отдельной команде на каждое
поле. Отрицательная форма команды отключает учет соответствующего поля в пакетах при
балансировке трафика.
Синтаксис
[no] load-balancing hash-fields { ip-dst | ip-src | mac-dst | mac-src | mpls }
Параметры
• ip-dst — IP-адрес получателя в IP-пакете;
• ip-src — IP-адрес отправителя в IP-пакете;
47
