![Eltex ME5000 [460/670] Join prune holdtime](/views2/1569351/page460/bg1cc.png)
Необходимый уровень привилегий
p10
Командный режим
config-router-pim-address-family-interface
Пример
0/ME5100:example_router01(config)# router pim address-family ipv4 interface
tengigabitethernet 0/0/7
0/ME5100:example_router01(config-tengigabitethernet)# hello-interval 60
0/ME5100:example_router01(config-tengigabitethernet)#
18.5. join-prune-holdtime
Время для удержания PIM-соседства со всеми соседями на данном интерфейсе.
Рекомендуется устанавливать минимум в 3,5 больше, чем join-prune-interval.
Отрицательная форма команды устанавливает значение по умолчанию (210).
Синтаксис
join-prune-holdtime SECONDS
no join-prune-holdtime
Параметры
• SECONDS — Время в секундах (0..65535).
Необходимый уровень привилегий
p10
Командный режим
config-router-pim-address-family-interface
Пример
0/ME5100:example_router01(config)# router pim address-family ipv4 interface
tengigabitethernet 0/0/7
0/ME5100:example_router01(config-tengigabitethernet)# join-prune-holdtime 300
0/ME5100:example_router01(config-tengigabitethernet)#
18.6. join-prune-interval
Интервал между сообщениями PIM Join/Prune, которые отправляются с данного интерфейса.
Отрицательная форма команды устанавливает значение по умолчанию (60).
Синтаксис
join-prune-interval SECONDS
439
