Eltex ME5100 [513/670] Source port eq
![Eltex ME5100 [513/670] Source port eq](/views2/1569351/page513/bg201.png)
Отрицательная форма команды возвращает значение по умолчанию (any).
Синтаксис
source { IPv4_ADDRESS | IPv4_PREFIX | IPv4_WILDCARD | any }
no source
Параметры
• IPv4_ADDRESS — IPv4-адрес (A.B.C.D)
• IPv4_PREFIX — IPv4-префикс (A.B.C.D/N)
• IPv4_WILDCARD — IPv4-префикс в формате wildcard (A.B.C.D/A.B.C.D)
• any — не задано, в правило попадает пакет с любым IP-адресом источника
Необходимый уровень привилегий
p10
Командный режим
config-ipv4-access-list-entry
Пример
0/FMC0:example_router01(config)# ipv4 access-list List1
0/FMC0:example_router01(config-access-list)# entry 10
0/FMC0:example_router01(config-entry)# source 172.16.0.0/24
0/FMC0:example_router01(config-entry)#
22.12. source-port eq
Команда задает значение порта-источника пакета для сравнения в правиле списка досупа.
Отрицательная форма команды удаляет условие.
Синтаксис
source-port eq NUMBER
no source-port eq
Параметры
• NUMBER — номер порта (0..65535)
Необходимый уровень привилегий
p10
Командный режим
config-ipv4-access-list-entry
Пример
492
