Синтаксис
originator-ip IPv4_ADDRESS
no originator-ip
Параметры
• IPv4_ADDRESS — IP-адрес RP
Необходимый уровень привилегий
p10
Командный режим
config-router-msdp
config-router-msdp-vrf
Пример
0/ME5200:example_router01(config)# router msdp
0/ME5200:example_router01(config-msdp)# originator-ip 10.0.0.2
0/ME5200:example_router01(config-msdp)#
20.10. peer
Команда создает MSDP-сессию и переходит в режим конфигурирования ее параметров.
Отрицательная форма команды удаляет сессию и всю вложенную конфигурацию.
Синтаксис
[no] peer IPv4_ADDRESS
Параметры
• IPv4_ADDRESS — IP адрес-MSDP соседа
Необходимый уровень привилегий
p10
Командный режим
config-router-msdp
config-router-msdp-vrf
Пример
0/ME5200:example_router01(config)# router msdp
0/ME5200:example_router01(config-msdp)# peer 10.0.0.1
0/ME5200:example_router01(config-peer)#
