0/ME5100:example_router01(config)# prefix-list Test
0/ME5100:example_router01(config-prefix-list)# seq-num 10
0/ME5100:example_router01(config-seq-num)# action deny
0/ME5100:example_router01(config-seq-num)#
13.102.2. community
Команда задает значение BGP community в элементе списка ip-community.
Отрицательная форма команды удаляет настройку
Синтаксис
[no] community COMMUNITY
[no] community WELL-KNOWN-COMMUNITY
Параметры
• COMMUNITY — числовое значение BGP community (0..4294967295, 0..65535:0..65535)
• WELL-KNOWN-COMMUNITY:
◦ accept-own — Accept own
◦ accept-own-nexthop — Accept own nexthop
◦ blackhole — Blackhole
◦ gshut — Graceful Shutdown
◦ internet — Internet
◦ llgr-stale — Stale llgr
◦ local-as — Do not send outside local AS
◦ no-advertise — Do not advertise to any peer
◦ no-export — Do not export to next AS
◦ no-llgr — No llgr
◦ nopeer — Nopeer
◦ route-filter-translated-v4 — Route filter translated v4
◦ route-filter-translated-v6 — Route filter translated v6
◦ route-filter-v4 — Route filter v4
◦ route-filter-v6 — Route filter v6
Необходимый уровень привилегий
p10
Командный режим
config-ip-community-seq-num-type-standard
Пример
337
