![Eltex ME5100 [235/670] Lsp refresh interval](/views2/1569351/page235/bgeb.png)
Командный режим
config-router-isis
config-router-isis-vrf
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# lsp max-lifetime 400
0/ME5100:example_router01(config-isis)#
12.37. lsp refresh-interval
Команда задает время пересчета LSP.
Отрицательная форма команды задает значение по умолчанию (900).
Синтаксис
lsp refresh-interval SECONDS
[no] lsp refresh-interval
Параметры
• SECONDS — время обновления LSP в секундах.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis
config-router-isis-vrf
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# lsp refresh-interval 100
0/ME5100:example_router01(config-isis)#
12.38. lsp-interval
Данная команда задает значение IS-IS таймера, используемого для настройки задержки
между успешными передачами IS-IS Link-state Packets (LSPs).
Отрицательная форма команды возвращает значение по умолчанию (100).
Параметры
• MILLISECONDS — интервал между приемом двух последовательных LSPs в
миллисекундах (1..65535).
