![Eltex ME5100 [548/670] Port priority](/views2/1569351/page548/bg224.png)
node-id (0-7)
no node-id
Параметры
• 0..7 — Номер узла в MCLAG-группе.
Необходимый уровень привилегий
p10
Командный режим
config-lacp-redundancy-groups-redundancy-group
Пример
0/ME5100:example_router01(config)# lacp redundancy-groups redundancy-group 10
0/ME5100:example_router01(config-redundancy-group)# node-id 1
0/ME5100:example_router01(config-redundancy-group)#
24.18. port-priority
Задание приоритета в LACPDU для bundle-интерфейса.
Отрицательная форма команды устанавливает значение по умолчанию (32768).
Синтаксис
port-priority (0-65535)
no port-priority
Параметры
• (0-65535) — Задание приоритета
Необходимый уровень привилегий
p10
Командный режим
config-lacp-interface
Пример
0/ME5100:example_router01(config)# lacp interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# port-priority 100
0/ME5100:example_router01(config-tengigabitethernet)#
24.19. show lacp bundle-ether
Вывод информации о группе агрегации, её членах, партнерах и связанных протоколах: BFD,
MC-LAG.
527
