Отрицательная форма команды удаляет настройку.
Синтаксис
[no] shutdown
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-interface
config-router-isis-interface-address-family-ipv4-unicast
config-router-isis-interface-address-family-ipv6-unicast
config-router-isis-vrf-interface
config-router-isis-vrf-interface-address-family-ipv4-unicast
config-router-isis-vrf-interface-address-family-ipv6-unicast
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# interface tengigabitethernet 0/0/8.10
0/ME5100:example_router01(config-tengigabitethernet-sub)# shutdown
0/ME5100:example_router01(config-tengigabitethernet-sub)#
12.76. spf interval maximum-wait
Данная команда устанавливает в конфигурации таймер, который устанавливает
количество времени между двумя последовательными пересчетами алгоритма Shortest Path
First (SPF).
Отрицательная форма команды возвращает значение по умолчанию (5000).
Синтаксис
spf interval maximum-wait MILLISECONDS
[no] spf interval maximum-wait
Параметры
• MILLISECONDS — значение таймера maximum-wait в миллисекундах (0..120000).
Необходимый уровень привилегий
p10
Командный режим
config-router-isis
config-router-isis-vrf
251
