Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show ospfv2 interfaces
Fri Jul 21 11:00:12 2017
Ê Routing Process: test, with ID 22.22.22.22
Ê Router is an area border router
Ê Area 0.0.0.0, up
Ê Interface Tengigabitethernet 0/0/1.101, state: designated-router, status: up
Ê Changed state: 2 time, Administrative group 0
Ê Designated Router IP addr: 10.10.24.32
Ê Backup Designated Router IP addr: 0.0.0.0
Ê Subnet mask: 255.255.255.0
Ê Remote peer index: 0
Ê Number of LSA count: 0, checksum: 0x00000000
Ê Area 0.0.0.1, up
Ê Interface Tengigabitethernet 0/0/2, state: point-to-point, status: up
Ê Changed state: 5 time, Administrative group 0
Ê Designated Router IP addr: 0.0.0.0
Ê Backup Designated Router IP addr: 0.0.0.0
Ê Subnet mask: 255.255.255.0
Ê Remote peer index: 0
Ê Number of LSA count: 0, checksum: 0x00000000
Ê Interface Loopback 7999, state: loopback, status: up
Ê Changed state: 1 time, Administrative group 0
Ê Designated Router IP addr: 0.0.0.0
Ê Backup Designated Router IP addr: 0.0.0.0
Ê Subnet mask: 255.255.255.255
Ê Remote peer index: 0
Ê Number of LSA count: 0, checksum: 0x00000000
11.70. show ospfv2 interfaces link-state
Данная команда отображает LSA Type 2 информацию по всем интерфейсам.
Синтаксис
show ospfv2 [vrf { all | VRF_NAME }] interfaces link-state
Параметры
• VRF_NAME — имя Virtual Routing and Forwarding сущности.
Необходимый уровень привилегий
180
