Параметры
• NAME — строковое значение имени pseudowire (0..16)
Необходимый уровень привилегий
p10
Командный режим
config-l2vpn-bridge-domain-pw
config-l2vpn-bridge-domain-vfi-pw
config-l2vpn-xconnect-group-p2p-pw
Пример
0/ME5100:example_router01(config)# l2vpn xconnect-group test
0/ME5100:example_router01(config-xconnect-group)# p2p pw1
0/ME5100:example_router01(config-p2p)# pw 172.16.0.2 100
0/ME5100:example_router01(config-pw)# name Pw1
0/ME5100:example_router01(config-pw)#
15.26. p2p
Данная команда создает в конфигурации устройства кросс-коннект (point-to-point
соединение) и переходит в режим его настройки.
Кросс-коннекты являются одним из двух основных механизмов Layer2-коммутации на
устройстве. В кросс-коннект может быть включено не более двух точек входа-выхода. В
качестве таких точек могут использоваться интерфейсы (attachment circuits) и MPLS
pseudowires. Кросс-коннект производит безусловную передачу Ethernet-кадра, полученного
по одной из своих точек входа-выхода, во вторую точку входа-выхода. Изучение MAC-
адресов в кросс-коннекте не производится.
Отрицательная форма команды удаляет данное P2P-соединение из конфигурации.
Синтаксис
[no] p2p STRING
Параметры
• STRING — имя кросс-коннекта, (1..128).
Необходимый уровень привилегий
p10
Командный режим
config-l2vpn-xconnect-group
Пример
402
