Eltex ME5100 [377/670] 4 set extcommunity set specific soo value
![Eltex ME5100 [377/670] 4 set extcommunity set specific soo value](/views2/1569351/page377/bg179.png)
• RT — значение BGP extended community RT (0..65535:0..4294967295,
0..4294967295:0..65535, IPv4:0..65535)
Необходимый уровень привилегий
p10
Командный режим
config-route-map-seq-num
Пример
0/ME5100:example_router01(config)# route-map Test
0/ME5100:example_router01(config-route-map)# seq-num 10
0/ME5100:example_router01(config-seq-num)# set extcommunity set-specific rt value
65535:1
0/ME5100:example_router01(config-seq-num)#
13.102.34. set extcommunity set-specific soo value
Команда задает значение BGP extended community типа SoO(Site of Origin) для добавления
маршрутам, удовлетворяющим условиям указанного правила route-map
Отрицательная форма команды удаляет настройку
Синтаксис
set extcommunity set-specific soo value SOO
no set extcommunity set-specific soo value
Параметры
• SOO — значение BGP extended community SoO (0..65535:0..4294967295,
0..4294967295:0..65535, IPv4:0..65535)
Необходимый уровень привилегий
p10
Командный режим
config-route-map-seq-num
Пример
0/ME5100:example_router01(config)# route-map Test
0/ME5100:example_router01(config-route-map)# seq-num 10
0/ME5100:example_router01(config-seq-num)# set extcommunity set-specific soo value
65535:1
0/ME5100:example_router01(config-seq-num)#
356
