Отрицательная форма команды удаляет исключение.
Синтаксис
[no] lfa exclude
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-interface
config-router-isis-vrf-interface
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# lfa exclude
0/ME5100:example_router01(config-tengigabitethernet)#
12.31. lfa filter
Данная команда создает в конфигурации именованное правило фильтрации маршрутов,
для которых и из которых будут расчитываться альтернативы.
Отрицательная форма команды удаляет данное правило.
Синтаксис
[no] lfa filter STRING
Параметры
• STRING — имя правила (1..128).
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-address-family-ipv4-unicast
config-router-isis-address-family-ipv6-unicast
config-router-isis-vrf-address-family-ipv4-unicast
config-router-isis-vrf-address-family-ipv6-unicast
Пример
210
