Eltex ME5100 [106/670] Logging buffered size
![Eltex ME5000 [106/670] Logging buffered size](/views2/1569351/page106/bg6a.png)
no logging buffered severity
Параметры
В качестве аргументов данной команды используются зарезервированные ключевые
слова, обозначающие уровни критичности. Указание ключевого слова none отключает
запись любых сообщений в журнал событий устройства.
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# logging buffered severity info
7.6. logging buffered size
Данная команда задает максимальный размер файлов журнала, используемых системой
журналирования устройства в процессе ротации. При достижении файлом заданного
размера он подлежит ротации, при этом старый файл удаляется.
Отрицательная форма команды устанавливает значение по умолчанию (10000 KiB).
Синтаксис
logging buffered size FILE_SIZE
no logging buffered size
Параметры
• FILE_SIZE — максимальный размер файлов журнала, хранящихся на устройстве в
процессе ротации, указывается в KiB. Может принимать значения от 100 до 100000
KiB.
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# logging buffered size 20000
85
