Eltex ME5100 [299/670] Dampening max suppress time
![Eltex ME5100 [299/670] Dampening max suppress time](/views2/1569351/page299/bg12b.png)
Синтаксис
dampening half-life MINUTES
no dampening half-life
Параметры
• MINUTES — значение half-life интервала в минутах, диапазон значений: 1..45.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-address-family-ipv4-unicast
config-router-bgp-address-family-ipv6-unicast
config-router-bgp-address-family-l2vpn-vpls
config-router-bgp-address-family-vpnv4-unicast
config-router-bgp-address-family-vpnv6-unicast
config-router-bgp-vrf-address-family-ipv4-unicast
config-router-bgp-vrf-address-family-ipv6-unicast
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# dampening half-life 10
0/ME5100:example_router01(config-unicast)# no dampening half-life
13.34. dampening max-suppress-time
Команда задает максимальное время удержания маршрута в отложенном состоянии.
Отрицательная форма команды возвращает значение по умолчанию (60).
Синтаксис
dampening max-suppress-time MINUTES
no dampening max-suppress-time
Параметры
• MINUTES — время в минутах, диапазон значений: 1..255.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-address-family-ipv4-unicast
config-router-bgp-address-family-ipv6-unicast
config-router-bgp-address-family-l2vpn-vpls
config-router-bgp-address-family-vpnv4-unicast
config-router-bgp-address-family-vpnv6-unicast
278
