Eltex ME5100 [306/670] Martian check disable
![Eltex ME5100 [306/670] Martian check disable](/views2/1569351/page306/bg132.png)
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-neighbor
config-router-bgp-peergroup
config-router-bgp-vrf-neighbor
config-router-bgp-vrf-peergroup
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# neighbor 10.0.0.10
0/ME5100:example_router01(config-neighbor)# local-as 65000
0/ME5100:example_router01(config-neighbor)# no local-as
13.44. martian-check disable
Команда отключает проверку маршрутов на вхождение в зарезервированные диапазоны
(martians check) в указанной Address Family.
Отрицательная форма команды возвращает поведение по умолчанию, включает проверку.
Синтаксис: [no] martian-check disable
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-address-family-ipv4-unicast
config-router-bgp-address-family-ipv6-unicast
config-router-bgp-vrf-address-family-ipv4-unicast
config-router-bgp-vrf-address-family-ipv6-unicast
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# martian-check disable
0/ME5100:example_router01(config-unicast)# no martian-check disable
13.45. match nexthop
Команда включает фильтрацию маршрутов перераспределяемых в указанном правиле
285
