Командный режим
config-router-ospfv2
config-router-ospfv2-area-interface
config-router-ospfv2-vrf
config-router-ospfv2-vrf-area-interface
config-router-ospfv3
config-router-ospfv3-area-interface
config-router-ospfv3-vrf
config-router-ospfv3-vrf-area-interface
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# area 0.0.0.0
0/ME5100:example_router01(config-area)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# lfa
0/ME5100:example_router01(config-tengigabitethernet)#
IMPORTANT
Механизм LFA работает только для point-to-point интерфейсов (см.
директиву network).
11.27. lfa exclude
Команда запрещает расчет альтернативных маршрутов через данный интерфейс.
Отрицательная форма команды возвращает поведения по умолчанию, при включении lfa, в
расчете альтернативных маршрутов участвуют все интерфейсы процесса OSPF.
Синтаксис
[no] lfa exclude
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-area-interface
config-router-ospfv2-vrf-area-interface
config-router-ospfv3-area-interface
config-router-ospfv3-vrf-area-interface
Пример
147
