0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# lfa filter FILTER
0/ME5100:example_router01(config-filter)#
12.32. lfa include-all
Команда разрешает расчет альтернативных маршрутов для всех интерфейсов,
участвующих в IS-IS процессе маршрутизации.
Отрицательная форма команды возвращает поведение по умолчанию, включение LFA
защиты производится для каждого интерфейса отдельно.
Синтаксис
[no] lfa include-all
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-address-family-ipv4-unicast
config-router-isis-address-family-ipv6-unicast
config-router-isis-vrf-address-family-ipv4-unicast
config-router-isis-vrf-address-family-ipv6-unicast
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# lfa include-all
0/ME5100:example_router01(config-unicast)#
12.33. lfa protection disable
Команда выключает расчет альтернативных маршрутов для данного интерфейса.
Отрицательная форма команды возвращает поведение по умолчанию, при использовании
команды lfa include-all альтернативные маршруты рассчитываются для всех интерфейсов.
Синтаксис
[no] lfa protection disable
Параметры
Команда не содержит аргументов.
211
